MC Series

Charge Only Controller

MPPT | 12V/24V/36V/48V | 60-100A
Download PDF Contact
MC Series 60-100A
Home | Solar Charge Controller| Charge Only Controller
60A 100A Solar Charge Controller

For off-grid application

Connect to photovoltaic and supply power to batteries.
60A 100A Solar Charge Controller

All-in-One

Supports multiple battery types.Support 1-10 PCS in parallel.
60A 100A Solar Charge Controller

User-Friendly

Easy to install and simple to use.Natural cooling, absolutely quiet.
60A 100A Solar Charge Controller

Efficient

MPPT with up to 99.9% efhciency.Support solar panel 2 in series/more in parall.
60A 100A Solar Charge Controller

Safety

Complete charge protection mechanism.
60A 100A Solar Charge Controller

Intelligent

Supports TTL RS485 communication.Supports Bluetooth with mobile APP.

OVERVIEW

60A 100A Solar Charge Controller
Model
MC4885N15
Max.Voltage of Open Circuit
150Vdc
Rated Battery Voltage
12/24/36/48Vdc
Rated Charging Current
85A
Battery Voltage Range
9~64Vdc
MPPT Tracking Efficiency
>99%
Weight
5.7kg (12.57lb)
Dimension
314*227*121mm
Model
MC48100N15
Max.Voltage of Open Circuit
150Vdc
Rated Battery Voltage
12/24/36/48Vdc
Rated Charging Current
100A
Battery Voltage Range
9~64Vdc
MPPT Tracking Efficiency
>99%
Weight
5.7kg (12.57lb)
Dimension
314*227*121mm
Model
MC4885N25
Max.Voltage of Open Circuit
250Vdc
Rated Battery Voltage
12/24/36/48Vdc
Rated Charging Current
85A
Battery Voltage Range
9~64Vdc
MPPT Tracking Efficiency
>99%
Weight
5.7kg (12.57lb)
Dimension
314*227*121mm
Model
MC48100N25
Max.Voltage of Open Circuit
250Vdc
Rated Battery Voltage
12/24/36/48Vdc
Rated Charging Current
100A
Battery Voltage Range
9~64Vdc
MPPT Tracking Efficiency
>99%
Weight
5.7kg (12.57lb)
Dimension
314*227*121mm
Model
MC4860N15
Max.Voltage of Open Circuit
150Vdc
Rated Battery Voltage
12/24/36/48Vdc
Rated Charging Current
60A
Battery Voltage Range
9~64Vdc
MPPT Tracking Efficiency
>99%
Weight
3.6kg (7.94lb)
Dimension
266*194*119mm
Model
MC4870N15
Max.Voltage of Open Circuit
150Vdc
Rated Battery Voltage
12/24/36/48Vdc
Rated Charging Current
70A
Battery Voltage Range
9~64Vdc
MPPT Tracking Efficiency
>99%
Weight
3.6kg (7.94lb)
Dimension
266*194*119mm
Model
MC4860N25
Max.Voltage of Open Circuit
250Vdc
Rated Battery Voltage
12/24/36/48Vdc
Rated Charging Current
60A
Battery Voltage Range
9~64Vdc
MPPT Tracking Efficiency
>99%
Weight
3.6kg (7.94lb)
Dimension
266*194*119mm
Model
MC4870N25
Max.Voltage of Open Circuit
250Vdc
Rated Battery Voltage
12/24/36/48Vdc
Rated Charging Current
70A
Battery Voltage Range
9~64Vdc
MPPT Tracking Efficiency
>99%
Weight
3.6kg (7.94lb)
Dimension
266*194*119mm
