HESP 14-18kW

Hybrid Inverters

Three-Phase Hybrid Solar Storage Inverter
HESP 14-18kW

Efficient

3 independent MPPT ports, up to 1.6 times the rated photovoltaic power.
hybrid inverter
hybrid solar inverter

Waterproof protection

Outputs high quality pure sine wave AC power.IP65 protection degree for outside installation

User-friendly

Support time-slot function for peak-valley.
hybrid inverter

Safety

AC coupling function

All-in-one

With a dual activation function (grid or PV).

Intelligent

Smart load function.

OVERVIEW

hybrid inverter
Model
HESP48140UH3
Rated AC Input/Output Active Power
14000W
Rated AC Input/Output Current
44.5A/38.8A
Peak Power (off-grid)
28000VA
Number of Battery Input
2
Battery Voltage Range
40V-60V
Max. PV Access Power
28000W
Max. PV Input Power
22400W
Model
HESP48160UH3
Rated AC Input/Output Active Power
16000W
Rated AC Input/Output Current
50A/44.5A
Peak Power (off-grid)
32000VA
Grid Connection Form
3L+N+PE
Battery Voltage Range
40V-60V
Max. PV Access Power
32000W
Max. PV Input Power
25600W
Model
HESP48180UH3
Rated AC Input/Output Active Power
18000W
Rated AC Input/Output Current
55.5A/50A
Peak Power (off-grid)
36000VA
Max. Hybrid Charging Current
350A
Max. PV Access Power
36000W
Max. PV Input Power
28800W
Max. PV Input Voltage
600V
