HESP 8-12kW

Single Phase Low Voltage Hybrid Inverter

8-12kW | Three Phase | 2 MPPTs
Download PDF Contact
HESP 8-12kW-EU
Home | Residential Hybrid Inverter| Single Phase Low Voltage Hybrid Inverter

Efficient

Compatible with 48Vstorage batteries
5kw Hybrid Solar Inverter
5kw Hybrid Solar Inverter

Waterproof protection

IP65 for outdoor installation

User-friendly

2 efficient, independent MPPT ports
5kw Hybrid Solar Inverter

Safety

Separate generator port

Intelligent

Support three-phase pure sine wave output

Communication

Support time-slot function for peak-valley

OVERVIEW

5kw Hybrid Solar Inverter
Model
HESP4880SH3
Rated Output Power
8,000W
Max. Peak Power
16,000VA
Load Motor Capacity
5HP
Switch Time
10ms
Rated Battery Voltage
48V
Max. Grid/Generator Charging Current
100A
No. of MPPT Trackers
2
Model
HESP48100SH3
Rated Output Power
10,000W
Max. Peak Power
20,000VA
Load Motor Capacity
6HP
Rated Frequency
50/60Hz ± 0.3Hz
Battery Volatge Range
40～60Vdc
Num. of MPPT Trackers
2
Bypass Overload Current
29A
Model
HESP48120SH3
Rated Output Power
12,000W
Max. Peak Power
24,000VA
Max. Grid/Generator Charging Current
120A
Max. Discharge Current
260A
Max. Input Power
9,000W+9,000W
Num. of MPPT Trackers
2
Bypass Overload Current
35A
