ABP Serie

Off Grid Solar Inverter

4-10KW | Split/Single-Phase
Download PDF Contact
ABP Serie 4-10KW
Home | Solar Power Inverter| Off Grid Solar Inverter

Efficiente

Solar Charger Controller up to 140A charging current
5kw Hybrid Solar Inverter
5kw Hybrid Solar Inverter

Protezione impermeabile Grado di protezione

Optional CT improves safety and reliability

Installazione conveniente

Support SUB working mode: support Grid and PV hybrid charging
5kw Hybrid Solar Inverter

Sicurezza

Supports both mains and generator power input with intelligent switching

Intelligente

Support time-sharing charge and discharge function

Comunicazione

Support 6 parallel machines up to 39kW

OVERVIEW

5kw Hybrid Solar Inverter
Model
ABP4840U100-H
Rated Output Power
4000W
Max. Output Power
8,000VA
Rated Output Voltage
120/240 Vac (single-phase/split-phase)
Load capacity of Motors
50Hz/60Hz
Parallel Capacity
1～6 Units
Num. of MPPT Trackers
1+1
Max. Open Circuit Voltage
550Vdc+550Vdc
Model
ABP4850U120-H
Rated Output Power
5000W
Max. Output Power
10000VA
Rated Output Voltage
120/240 Vac (single-phase/split-phase)
Load capacity of Motors
50/60Hz
Parallel Capacity
1～6 Units
No. Of MPPT
1+1
Max. Open Circuit Voltage
550Vdc+550Vdc
Model
ABP4860U140-H
Rated Output Power
6000W
Max. Output Power
12000VA
Rated Output Voltage
120/240 Vac (single-phase/split-phase)
Load capacity of Motors
50/60Hz
Parallel Capacity
1～6 Units
No. Of MPPT
1+1
Max. Open Circuit Voltage
550Vdc+550Vdc
Model
ABP4865U140-H
Rated Output Power
6500W
Max. Output Power
13000VA
Rated Output Voltage
120/240 Vac (single-phase/split-phase)
Load capacity of Motors
50/60Hz
Rated Battery Voltage
48V
Max. Input Current
18A+18A
No. Of MPPT
1+1
Model
ABP48100U200-H
Rated Output Power
10,000W
Max. Output Power
20,000VA
Rated Output Voltage
120/240 Vac (single-phase/split-phase)
Rated Frequency
50/60Hz
Rated Battery Voltage
48V
Max. Solar Charging Current
200A
No. Of MPPT
1+1
Model
ABP4880U180-H
Rated Output Power
8,000W
Max. Output Power
16,000VA
Rated Output Voltage
120/240 Vac (single-phase/split-phase)
Rated Frequency
50/60Hz
Max. Solar Charging Current
180A
Max. Mix Charge Current
180A
No. Of MPPT
1+1
