HFP 5kW

Single/Split Phase Low Voltage

EU | Single Phase | 1 MPPTs
HFP 5kW-EU

Efficient

Advanced MPPT with up to 99.9% efficiency.Multiple charge and discharge modes are available
hybrid inverter
hybrid solar inverter

Reliable

Outputs high-quality pure sine wave AC power.Reliable output for long periods at rated power.

User-friendly

Industrial design with a modern aesthetic look.Easy to install and simple to use.
hybrid inverter

Safety

360 degrees of security from hardware to software.With IEC, SAA, cETL ,FCC certification.

All-in-one

Support for many types of batteries.Supports Li-ion battery BMS communication.

Intelligent

Exclusive Li-ion battery BMS dual activation.Support for remote monitoring of operating parameters.

OVERVIEW

hybrid inverter
Model
HFP4850S80-145
Rated Output Power
5,000W
Max.Peak Power
10000VA
Rated Output Voltage
230Vac±5%
Load Motor Capacity
3HP
Rated Frequency
50/60Hz
Waveform
Pure sine wave
Switch Time
10ms(typical)
Model
HFP4850S80-H
Rated Output Power
5,000W
Max.Peak Power
10000VA
Rated Output Voltage
230Vac±5%
Rated Output Frequency
50/60Hz
Load Motor Capacity
4HP
Rated Battery Voltage
48V
Battery Voltage Range
40~60V
